All-solid-state fully coherent, phased array X-band radar drone detection system

$45,000-46,850/pieces
Price
All-solid-state fully coherent, phased array X-band radar drone detection system
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Signal Detector
Application: Detector
Feature: Detection
Work System: All-solid-state Fully Coherent, Phased Array System
Operating Mode: Pulse Doppler
Working Frequency: X-band (5 Operating Frequency Points)
Maximum Detection Distance: ≥ 1.5km (micro Drone)
Minimum Detection Distance: ≤ 150m
Detection Speed: 0.5m/s~30m/s
Ground Clutter Improvement Factor: ≥ 60dB
Data Interface: RJ45, UDP Protocol Fast Ethernet
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Bambi
Payment & Shipping Terms
Product Description
Product Description
The X-band radar drone detection is mainly composed of a radar front high-speed turntable and a power distribution control box. It is used for the detection of low-altitude, low-slow and slow targets and moving targets on the ground and sea. It can be used for warning and target indication, and can give the target track information in real time and accurately. The X-band radar drone detection can monitor low, slow and small suspicious targets, capture the precise position of the target in real time, and achieve 360° full coverage of the supervision area without dead ends. The equipment adopts radar detection technology with independent intellectual property rights, which is suitable for all-weather, all-day, complex electromagnetic environment and geographical conditions, ensuring continuous and stable operation of the equipment 7*24 hours.
All-solid-state fully coherent, phased array X-band radar drone detection system 0
Product features
The X-band radar drone detection System adopts the automatic detection and tracking work mode, and the terminal display and control platform software realizes the target positioning and trajectory display functions on the map, and can display the target distance, azimuth, altitude and speed information in a list; has a multi-level alarm area setting function, which can set the alarm area arbitrarily, and different levels of areas are distinguished by different colors; has the function of intrusion alarm, different alarm modes can be adopted in different alarm areas; It has the function of setting the basic parameters of the radar, and can adjust the parameters of the working mode, detection threshold, emission switch, and front orientation; has the function of track record and playback of the target.
Technical Parameters
Item
Performance parameters
Work system
All-solid-state fully coherent, phased array system (azimuth scan + tilt phase scan)
Operating mode
Pulse Doppler
Working frequency
X-band (5 operating frequency points)
Maximum detection distance
≥ 1.5km (micro drone)
≥ 2.0km (pedestrian) / ≥ 3.0km (vehicle)
≥ 10.0km (fishing boat)
Minimum detection distance
≤ 150m
Detection range
Azimuth coverage: ≥ 360°
Elevation coverage: ≥ 40°
Detection speed
0.5m/s~30m/s
measurement accuracy
Azimuth measurement accuracy: ≤0.8°;
Tilt measurement accuracy: ≤1.0°;
Distance measurement accuracy: ≤10m;
Ground Clutter Improvement Factor
≥ 60dB
Simultaneous processing of targets
≥100
Data interface
RJ45, UDP protocol Fast Ethernet
All-solid-state fully coherent, phased array X-band radar drone detection system 1
Company Profile
All-solid-state fully coherent, phased array X-band radar drone detection system 2
All-solid-state fully coherent, phased array X-band radar drone detection system 3
FAQ

Q1: Why choose Bambi Tech? To provide our customers with first-class services in the supply of quality minimizing costs. Q2: How is quality ensured? All our processes strictly adhere to ISO9001:2009 procedures. From production to delivery, we have strict quality control. Ourcompany has strong technical support and has cultivated a group of managers who are familiar with product quality, good at modern concept of management. Q3: Can You Strictly Follow The Tolerance on The Drawing And Meet The High Precision? Yes, we can, we can provide high precision parts and make the parts as your drawing. Q4: How should I order and make payment? By T/T, for samples 100% with the order; for production, 40% paid for deposit by T/T before production arrangement, the balance to be paid before shipment. negotiation accepted. Q5: What’s your Delivery Time? Standard parts: 3-20days Non-standard parts: 15-25days We will make the delivery as soon as possible with the guarantee quality. Q6: Which mode of transport would be better? In general, the product are heavy, we advice to make delivery by sea, Also we respect your views of other transportation as well. Q7: How to Custom-made (OEM/ODM)? If you have a new product drawing or a sample, please send to us, and we can custom-made the as your required. We will also provide our professional advices of the products to make the design to be more realized & maximize the performance.
