Handheld Accurately Locate UAS Locator

$100-5,000/pieces
Price
Handheld Accurately Locate UAS Locator
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Detect
Feature: Detect
Basic Infomation
Place of Origin: China
Payment & Shipping Terms
Product Description
Product Description
Handheld Accurately Locate UAS Locator 0
Specification
#
Index
Parameter
Notes
1
Locatable drone models
DJY, Air, Mini, FPV, Avata, etc
DJI with OcuSync protocols
2
Detection frequency band
2.4GHz、5.8GHz
3
Range
1~2km
Varies due to environment and drone model
4
Positioning accuracy
≤5m
Varies due to environment and drone model
5
Location refresh time
≤30s
1
Dimension
L*W*H(186mm*86mm*21mm)
2
Weight
(455±10)g
Without antenna
1
Battery capacity
4520mAh
Built in lithium battery
2
Battery life
~5 hours
Screen brightness is 20%, temperature is 25℃
3
Charging duration
~1.5 hours
Using the original charger
1
Working temperature
-20~50℃
2
Storage temperature
-25~60℃
1
Screen size
6.67 inches
AMOLED
2
Screen resolution
2400 * 1080 pixels
3
Screen refresh rate
120Hz
1
Memory
8GB
2
Storage
128GB
2
Network environment
Supports internet and single machine offline mode operation
Product Function
1)Drone Positioning [1]: A singleAAT-H1L-D can locate the coordinate of a drone, which can be displayed in the form of a "drone icon" on the device screen. 2)Pilot Positioning [2]: Single machine can locate the position of the remote control (pilot), which can be displayed on the device screen as a "remote control icon". 3)Pilot Position Navigation[3]:AAT-H1L-D can plan the route for searching for drone controllers and provide a "one click position navigation" function. 4)Unique Identification [4]: Can recognize the unique serial number (SN) of the DJI series (with OcuSync protocol) drone. 5)Trajectory Tracking [5]: It can display the flight trajectories of multiple drones simultaneously on the electronic map interface. 6)Multidimensional Information Monitoring[6]: It can display real-time information such as the current drone model, position information (longitude and latitude), speed, altitude, and pilot position (longitude and latitude) in the detection list column. 7)Black and Whitelist[7]: A white list can be set, and the device wont alarm once a whitelist drone is detected. Note: [1] [2] [3] [4][5][6][7] only applies to DJI series with OcuSync protocols. 8)Intrusion Alarm: When a drone intrusion is detected, the device will give an alarm through sound, light, vibration, and other means. 9)Data Playback: Supports the historical track playback function, assisting security personnel in analyzing historical drone flight data. 10)Detection Record: The detection record list can retain historical detection records, including multidimensional information such as drone serial number, model, frequency, etc. 11)Visual Data Analysis: Support drone detection and flight data statistical analysis, which can be displayed through a graphical interface.
Product features
1)Passive detection: does not emit any electromagnetic signals, possesses no electromagnetic environmental pollution, environmentally friendly. 2)Large touch screen interaction: Adopting a 6.67-inch large screen touch design, the operation is simple, convenient, and fast. 3)Mobile and portable: Exquisite and lightweight in appearance, easy to hold and carry, switch on ready to use. 4)Long lasting endurance: Equipped with a 4500mAh high capacity battery, it can operate continuously for up to 5 hours. 5)Standard charging interface: Type-c standard charging interface, can be connected to an external power adapter or mobile power supply for charging.
