UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection

$5,000-5,260/pieces
Price
UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Signal Detector
Feature: Signal Detector
Drone Positioning: Can Locate The Coordinate Of A Drone
Locatable Drone Models: DJY, Air, Mini, FPV, Avata, Etc
Detection Frequency Band: 2.4GHz,5.8GHz
Range: 1~2km
Positioning Accuracy: ≤5m
Basic Infomation
Place of Origin: China
Payment & Shipping Terms
Product Description
Product Description
Handheld UAV locator is a portable product that integrates RF sensing, protocol decoding, remote identification (RID) and other functions. AAT-H2L-D can realize real-time detection of drones and flight paths, as well as precise positioning of drones and remote controllers. Use radio signals transmitted between drones and remote controllers or ground stations for detection and positioning. By receiving specific interference signals emitted by drones, analyzing the strength, frequency, phase and other characteristics of the signals, the location and flight status of the DEVICE can be determined, as well as the position of the pilots can be accurately located. The operation interface is simple and clear, equipped with an LCD display, which can display the brand, model, distance and location of the drone.
UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection 0
Product Function
UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection 1
UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection 2
1)uav positioning[1]:Locates the uav and shows the results as icons of UAV on the e-map. 2)Pilot positioning[2]:Locates the remote controllers (pilots), and shows the results as icons of the remote controllers on the e-map. 3)Vast drone data library[3]:Identifies over 700 types of drones, including DJI, AUTEL, FPVs and DIY UAV. 4)Pilot navigation[4]: H2L plans the route for tracking UAV controllers with easy operation. 5)RID detection[5]:H2L is able to identify DJI UAV (with OcuSync protocol), UAV with RID, and the unique serial number (SN) of WIFI UAV. 6)Comprehensive information[6]:Realtime display of the uav model, coordinates, velocity, altitude, pilot coordinates and so on. 7)Black and white list[7]:Once a white list is set, the alarm of H2L will not be set off if the uav in white list is detected. 8)Early warning:The device will alarm by beeping or vibrating when detects the uav.
Technical Parameters
Indicator
Parameter
Screen size
6-inch
Screen resolution
2160*1080 pixels
Frequency range
100MHz ~ 6GHz
Working range
0.5 ~ 1.5 km
Response time
3 ~ 5s
Swarm detection
~ 5
Memory
8GB
Storage
256GB
Operating system
Android 12
Network environment
Online / Offline
Battery life
3 ~ 4h
Operating temperature
-25~40℃
Storage temperature
-35~40℃
UAV Detector System Dual-band 2.4/5.8G Handheld Accurately Locate Detection 3
