Item | Performance parameters |
Working frequency | Ku-band |
frequency adjustable | YES |
Transmit signal bandwidth | ≤40MHz |
System | One-dimensional active phased array |
Beam scanning method | Elevation electronic scanning, azimuth mechanical scanning |
The average power of the whole machine | < 100W |
Detection power | ≥ 3km(RCS=0.01㎡) |
blind spot | ≤ 200m |
Azimuth range | 360° |
Tilt | 30° |
Speed range | 0.8 ~ 80 m/s |
Distance accuracy | 10m |
Azimuth accuracy | 0.8° |
Tilt accuracy | 0.8° |
Speed accuracy | 1 m/s |
Detection probability | 85% |
data rate | 6s |
Multi-target detection capability | have |
networking capability | have |
track output protocol | UDP |
twenty one Waterproof and moisture-proof grade | IP66 |
