Item | Performance parameters |
work system | Phased array system (azimuth scan + pitch scan) |
Operating mode | Pulse Doppler |
Working frequency | C-band (5 operating frequency points) |
Maximum detection distance | ≥ 1.5km |
Minimum detection distance | ≤ 100m |
Detection range | Azimuth coverage: 0~360° Elevation coverage: 0~ 30° |
Detection speed | 0.5m/s~30m/s |
Data speed | 0.2 times/s |
measurement accuracy | Azimuth measurement accuracy: ≤1.0°; Tilt measurement accuracy: ≤1.0°; Distance measurement accuracy: ≤10m; |
Ground Clutter Improvement Factor | ≥ 60dB |
Simultaneous processing of targets | ≥100 |
Data interface | RJ45, UDP protocol Fast Ethernet |
working environment | Working temperature: -40℃~+55℃ Storage temperature: -45℃~+65℃ Waterproof grade: IP65 With rain-proof, dust-proof and sand-proof With moisture-proof, salt-fog and mildew-proof |
Dimension | 600mm*421mm*342mm |
weight | Radar array: ≤30.0kg Turntable: ≤28.0kg Power distribution control box: ≤8.0kg |
