Item | Parameter | Remarks |
Detection frequency band | 100MHz~6GHz | |
Detection distance | 2~5km | |
Number of detection targets | ≥20 sorties | simultaneous |
Detection mode | 360°Passive detection | |
Direction finding frequency band | 2GHz~6GHz | |
Direction finding distance | ≥3km | |
Number of direction finding targets | Not less than 3 sorties | simultaneous |
Directional accuracy | ~10° | |
DF refresh rate | 10-30 times/minute | |
positioning accuracy | ≤20m | |
Number of positioning trajectories | ≥5 sorties | simultaneous |
Scan spectrum range | 100MHz~6GHz | |
Detecting and identifying drone models | Common brands of drones such as DJI, Autel, Fimi, Dahua, and Yuneec, as well as most domestically produced models such as walkthrough and WiFi machines on the market | |
Weight | 15kg | Without power adapter |
size | φ*H (420*530) ± 5mm | |
power dissipation | ≤50W | |
supply voltage | AC 220V/DC 12V | |
working temperature | -40~65℃ | |
Protection level | IP65 |
