It is suitable for drone prevention and control operations such as temporary major security tasks, park inspections etc.
Item | Technical Parameters |
Operating mode | Passive detection |
Drone models | DJI series drones,FPVs, Yuneec, Hubsan, Hubson, Powervision, Tello drones etc. |
Working frequency | 2.4GHz,5.8GHz |
Detection range | 0-800 meters (urban environment, tested with DJI AIR2 as the target) |
Azimuth | 0°~360°(omnidirectional antenna) |
Recognition time | ≤2s |
False alarm rate | ≤once/day(In an anechoic chamber environment) |
Swarm detection | ≥10 concurrent drones |
Operating mode | Directional passive detection |
Action object | Some drones such as DJI (Phantom series and Yu series), Daotong and Hubson |
Working frequency | 2.4GHz and 5.8GHz |
Detection distance | 100-2000 meters (urban environment, tested with DJI AIR2 as the target) |
Probe azimuth | ≤±17.5°(Target 1km away with frequency locked) |
