Item | Performance indicators |
Receiving antenna array composition | Contains 4 B1/L1/G1 frequency receiving elements. |
Operating frequency | B1 1561M/L1 1575. 42M/G1 1601M |
Antenna polarization method | Right-hand circular polarization. |
Coverage | Azimuth angle 0°~360°, pitch angle 5°~90° |
B1/L1/G1 antenna LNA specifications | Low noise gain: 25. 0±2. 0dB; Output standing wave: ≤2. 0; Noise coefficient: ≤2. 0; In-band flatness: ±1dB. |
Burnout prevention indicators | The continuous wave power that the antenna port can withstand is not less than 10W. |
type | broadband, narrowband, pulse, frequency hopping, frequency sweep and mixed . |
